31 Mar 2009

The Hopkins Family Tree


On Sunday, Martin Crawford of the Agroforestry Research Trust, and star of the recent ‘A Farm for the Future’ programme, came round to my house to perform radical surgery on a tree of mine.  The tree in question (see below left), a dessert apple, had been suffering from an odd ailment which meant that no sooner had it come into leaf, than all the leaves fell off, which in turn meant it was unable to make any fruit.  Martin’s diagnosis had been that the tree had some kind of fungal virus, but was essentially healthy, and that given that none of the other apple trees suffered from the same thing, it was an ailment specific to that variety. The answer was to transform the tree into a ‘family tree’.


A family tree is basically a tree grafted with varieties other than the host tree. Different rootstocks will support different varieties. For instance, crabapple rootstocks will support the full range of apple varieties, so one tree could produce cookers as well as early and late dessert apples. I have seen a tree that grew plums, greengages and almond on the same tree. For people with a small garden and room for one tree, a family tree makes a lot of sense. There are some specialist nurseries that sell them.


The process of turning my ailing tree into a family tree began with cutting the 5 main limbs back, in order to create a good shape. Then Martin used a billhook to split the stump of each branch so as to create a split into which the graft wood could be inserted. In his basket of essential tools, Martin had graftwood of the 5 varieties we were to add to the tree, which had been cut in January and kept in the fridge since then. These were Winston (a late keeper), Cornish Aromatic (ditto), Beauty of Bath (an early dessert apple variety), Pigs Nose (ditto) and Cheddar Cross (a kind of late early…).


At his nursery, Martin has coppiced versions of each of these, which he uses for obtaining the graftwood he needs. Each piece was then cut into a tapered point (see top picture), which was then inserted into the split in the branch, held open by a large screwdriver. Two pieces were inserted into each branch, as an insurance policy in case one failed. If both take, it will be easy enough to cut the surplus one back in a year or so.

crawford5Once he had been all round the tree and inserted the graftwood into each branch, he then painted grafting wax onto the graft, so as to reduce risk of infection, and of the branch dying out before the graft had taken. One can use beeswax, but quite often local bees notice it is there and come and take it away! And that was it. Quite straightforward really when you know how.


Creating family trees means that new life can be breathed into fruit trees, and also that one can broaden the diversity of the fruit varieties that can be produced from the back garden. It also means that one can preserve some rare varieties alongside the more commonplace ones. If you ever need any incentive for that, I can only recommend once again that you read one of the finest things George Monbiot has ever written, his eulogy to the disappearing English apple. If it doesn’t bring tears to your eye, you’re a harder person than I.

Comments are now closed on this site, please visit Rob Hopkins' blog at Transition Network to read new posts and take part in discussions.


31 Mar 8:48pm

Can’t help mentioning that the N Devon orchards group ‘Orchards Live!’ has a top grafting course on Sat 11th April – cost £6. George might be pleased to know that, partly because of this group perhaps, the area of land under orchard in Devon is now growing for the first time since WW2.

risa b
31 Mar 9:39pm

>One can use beeswax, but quite often local bees notice it is there and come and take it away

Wow. learn something every day!

Graham Burnett
31 Mar 9:45pm

Great article Rob! Folks might be interested in a website I’ve created in celebration of a local orchard here in Southend , and synchronicity strikes again, your post appeared on the same day that I’ve at last found an affordable way of printing this ‘parish map’ of the orchard that I made in conjunction with clients at the day centre where I work, so now I intend to add more content to the site very soon… Watch this space as they say

Graham Burnett
31 Mar 9:48pm

Risa said >One can use beeswax, but quite often local bees notice it is there and come and take it away

>Wow. learn something every day!

I remember years ago Ben Law showing me his innoculated mushroom logs, he’d sealed in the wooden innoculating dowels with beeswax from hivesin Prickly Nut Wood – the bees came and got it back. He was very philosophical about it though, saying he had no right to take it from them in the first place…

31 Mar 11:36pm

If you live in the north of England, the Northern Fruit Group offer grafting and budding workshops to members for the cost of the rootstocks.

Membership costs £5 per annum.

I went to one recent workshop where those participating ranged from a lady accompanying her partner and am assistant estate manager wanting to grow the fruit trees originally planted in the orchard that are no longer commercially available.

Both left with grafted trees and were highly delighted, although I think she was more thrilled.

I was inspired to join because I have trees that do not cross-pollinate properly and the tree I need to sort the problem is not available commercially.

What was stunning about the workshop (and reflects Rob’s experience) was the availability of some 30 different lots of grafting material, most of which is not available commercially, all offered at no cost.

I have 5 potential trees growing on my plot, all varieties that I would struggle to find commercially, for about £10. Three of them will solve my problem and two were just for fun.

Next year I will know how successful I have been. Fingers crossed.

Margie Kepner
1 Apr 2:52am

Wonderful info and I hope to try it on one or more of my trees. Just a note about a term which I think is yours, not Martin Crawford’s: “fungal virus.” I think you can have a disease caused by a fungus, a bacterium, or a virus. They are separate creatures, requiring different treatments. fyi

Jennifer Lauruol
1 Apr 8:09pm

Rod Everett also does apple grafting workshops at the Middlewood Trust here in north Lancashire. He keeps many old and local northern varieties on hand, and sells on the grafted trees for £10 each, potted up.

2 Apr 9:10am

for apple and orchard info generally in the UK, google ‘national orchards forum’ or ‘common ground’

4 Apr 7:49pm

‘fungal virus’ is nonsense, hopefully a misquote

did no one else catch that
